Polygon TAMBORA G5 – 1X11 SRAM APEX
$5.500.00012 cuotas sin interés de $458.333 Efectivo/transferencia: $4.125.000
Guía de Talles
- Guía de Talles
- ¿Como Medir?
| ALTURA | TALLE | MEDIDA | ENTREPIERNA |
| 158-165cm | XS | 48-51 | 71-74 |
| 165-170cm | S | 51-53 | 75-78 |
| 170-179cm | M | 53-55 | 79-88 |
| 179-186cm | L | 55-58 | 89-98 |
| 186-195cm | XL | 58-61 | 99-102 |
Descripción
Componentes
CUADRO
ACX Gravel Frame, Internal Cable Routing, BB86 Press Fit BB, 12x142mm Thru-Axle, Flat Mount Disc, Sram UDH
HORQUILLA
Polygon Full Carbon Rigid fork, Flat Disc Brake, 12x100mm
TRANSMISION
CAMBIO TRASERO
Sram Apex 1, 11-Speed
ERGOS
Sram Apex 1, 11-Speed Shifter
PALANCAS
Praxis ALBA GR M30, 42T, 170mm
PIÑON
Sram PG-1130, 11-Speed, 11-42T
CADENA
KMC X111
FRENOS
FRENO DELANTERO
TRP HD-C711 HY-ROAD, Hydraulic Disc Brake, 160mm Rotor
FRENO TRASERO
TRP HD-C711 HY-ROAD, Hydraulic Disc Brake, 160mm Rotor
RUEDAS
LLANTA
Polygon Alloy Double Wall, 12x100mm, 32H, Novatec D791, 6 Bolt Hub, Stainless spokes, Brass Nipple, Tubeless Tape Installed
CUBIERTA
Vee Tire Co. Rail, 700x40C, 622×50, *Tubeless Ready
PUNTOS DE CONTACTO
MANUBRIO
Polygon Alloy flare, 31.8mm Clamp Diameter, 125mm Rise, 16 Degree Flare, 420mm Width (S-M), 440mm Width (L-XL)
ASIENTO
Selle Italia Superflow
PORTASILLA
Entity Carbon, 27.2 x 300mm (S,M,L) / 27.2 x 350mm (XL)
STEM
Entity Expert, 31.8mm Clamp, 7-Degree, 90mm (S,M) / 100mm (L, XL)
Geometria
| S | M | L | |
| Top Tube Length | 525 | 550 | 580 |
| Reach | 368 | 381 | 397 |
| Stack | 566 | 590 | 620 |
| Seat Tube Length | 405 | 449 | 493 |
| Chainstay Length | 425 | 425 | 425 |
| Head Tube Angle | 70 | 71.5 | 72 |
| Seat Tube Angle | 74.5 | 74 | 73.5 |
| BB Height | 277 | 277 | 277 |
| Wheelbase | 1017 | 1023 | 1045 |
| Head Tube Length | 140 | 160 | 190 |
| Bottom Bracket offset | 78 | 78 | 78 |
| Standover | 690 | 731 | 773 |
